llm-d is a Kubernetes-native distributed inference serving stack – a well-lit path for anyone to serve large language models at scale, with the fastest time-to-value and competitive performance per dollar for most models across most hardware accelerators.

With llm-d, users can operationalize GenAI deployments with a modular solution that leverages the latest distributed inference optimizations like KV-cache aware routing and disaggregated serving, co-designed and integrated with the Kubernetes operational tooling in Inference Gateway (IGW).

Built by leaders in the Kubernetes and vLLM projects, llm-d is a community-driven, Apache-2 licensed project with an open development model.

🧱 Architecture

llm-d adopts a layered architecture on top of industry-standard open technologies: vLLM, Kubernetes, and Inference Gateway.

Key features of llm-d include:

vLLM-Optimized Inference Scheduler: llm-d builds on IGW’s pattern for customizable “smart” load-balancing via the Endpoint Picker Protocol (EPP) to define vLLM-optimized scheduling. Leveraging operational telemetry, the Inference Scheduler implements the filtering and scoring algorithms to make decisions with P/D-, KV-cache-, SLA-, and load-awareness. Advanced teams can implement their own scorers to further customize, while benefiting from other features in IGW, like flow control and latency-aware balancing. See our Northstar design
Disaggregated Serving with vLLM: llm-d leverages vLLM’s support for disaggregated serving to run prefill and decode on independent instances, using high-performance transport libraries like NIXL. In llm-d, we plan to support latency-optimized implementation using fast interconnects (IB, RDMA, ICI) and throughput optimized implementation using data-center networking. See our Northstar design
Disaggregated Prefix Caching with vLLM: llm-d uses vLLM’s KVConnector to provide a pluggable KV cache hierarchy, including offloading KVs to host, remote storage, and systems like LMCache. We plan to support two KV caching schemes. See our Northstar design
- Independent (N/S) caching with offloading to local memory and disk, providing a zero operational cost mechanism for offloading.
- Shared (E/W) caching with KV transfer between instances and shared storage with global indexing, providing potential for higher performance at the cost of a more operationally complex system.
Variant Autoscaling over Hardware, Workload, and Traffic (🚧): We plan to implement a traffic- and hardware-aware autoscaler that (a) measures the capacity of each model server instance, (b) derive a load function that takes into account different request shapes and QoS, and (c) assesses recent traffic mix (QPS, QoS, and shapes) to calculate the optimal mix of instances to handle prefill, decode, and latency-tolerant requests, enabling use of HPA for SLO-level efficiency.
